| Model Type |
Industrial Wireless Network & Desktop |
| Tape Family |
MZe, TZe, HS |
| Tape Sizes |
3.5mm, 6mm, 9mm, 12mm, 18mm, 24mm, 36mm |
| Tape Length |
8m (26.25') |
| Tape Technology |
Laminated Thermal Transfer |
| Tape Types |
High Grade Laminated Bulk, Standard Laminated, Flexible ID, Extra Strength Adhesive, Heat Shrink Tube, Tamper-Evident, Non-Laminated, Iron-on Fabric, Acid Free |
| LCD Display |
Optional Touch Panel Display (PA-TDU-003) |
| Backlight |
Optional Touch Panel & Display (PA-TDU-003) |
| Maximum Print Resolution |
360 x 720 dpi (14 x 28 dots/mm) |
| Maximum Print Speed |
80 mm/sec (3.15 ips) |
| Keyboard |
Optional Touch Panel Display (PA-TDU-003) |
| Cutter |
Automatic w/ Strip Cutting Feature |
| Batteries |
Optional Li-ion Rechargeable Battery (PA-BT-4000LI), Requires Optional Battery Base (PA-BB-002) |
| Operation Mode |
Computer Connected (GDI Printer, Template), Connected to Host Peripheral (USB or Serial) |
| Printer Emulation |
Raster, ESC P, Text (Template/Form Mode) |
| ENERGY STAR® certified |
Yes |
| Control Panel |
On/Off, Feed/Cut, Wi-Fi On/Off Keys; Power, Low Battery, Wi-Fi & Error LED's |
| Power Switch |
Digital |
| Power Supply |
AC Adapter Standard, Optional Li-ion Battery |
| AC Adapter |
AD-9100ESA (Included) - 24VDC / 100-240VAC 50/60 Hz |
| Interface |
Wi-Fi WLAN (802.11b/g/n), LAN (10/100 Base-TX), USB 2.0, Host USB, Serial (RS-232C), Optional Bluetooth v2.1 (PA-BI-002) |
| Mobile Device Printing App |
Mobile Cable Label Tool, Mobile Transfer Express |
| Mobile Device Compatibility |
iOS 3.0 or Later, Android 1.6 or Later |
| Software Features |
| Microsoft Word/Outlook/Excel Add-ins |
Office 2000/2003/2007/2012/2013 |
| Fonts |
Resident: Helsinki, Letter Gothic; P-touch Editor Software: Brother & Compatible TrueType Fonts |
| Font Sizes |
Scalable Fonts |
| Font Styles |
Regular, Bold, Shadow, Outline, Horizontal Lines, Surround, Invert |
| Max. Print Height |
1.26' (32 mm) |
| Multi-Block |
P-touch Editor Software |
| Label Length Setting |
0.16' - 39.37' (4.06mm - 999.99mm) |
| Horizontal Alignment |
Left, Center, Right Justification |
| Vertical Printing |
P-touch Editor Software |
| Rotate Printing |
Yes |
| Text Insert |
Yes |
| Text Framing/Fill Pattern |
P-touch Editor Software |
| Multi-copy Print |
Up to 5,000 Copies |
| Memory |
6 MB |
| Memory for Transferred Data (Number) |
Up to 99 Template Files |
| Favorites Function Key |
Optional Touch Panel & Display (PA-TDU-003) |
| Download data to unit |
Yes |
| Built-in Designs/Templates |
Downloadable |
